Infinity INTERMEZZO 1.2s - Mechanical;Packaging Parts List

INTERMEZZO 1.2s
11
Mechanical/Packaging Parts List
Ref No. Description Part Number
MECHANICAL
1 GASKET, REAR 331106-001
2 12” Woofer C.M.M.D. Shielded, DCR 7.6 ohms ±10%, 335036-001
3 RABOS ASSEMBLY 336202-001
4 SCREW, 8-32 x .5 BLK, MS,PPH (16) 900201-008
5 GRILLE CUP (14) 333249-003
6 Front BAFFLE 335270-001
7 SCREW, 6-32 x .5 BLK, MS,PPH (12) 900301-008
AMPLIFIER (NOT FOR SALE)
8 GRILLE (See options below) 335735-040
9 DÉCOR TRIM PANEL (See options below) 335739-030
PACKAGING
10 RABOS KIT 335852-002
11 FOOT PAD (4) 335459-001
12 POWER CORD (15 ft) 336658-115
13 TOP END PAD 336213-001
14 BOTTOM END PAD 336213-002
15 CARTON 336504-001
16 OWNERS MANUAL 336204-001
17 WARRANTY CARD 335841-001
18 SURVEY CARD 335868-002
Description Part Number
Grille, Warm Platinum 335735-040
Grille, Midnight Blue 335735-050
Grille, Rich Burgundy 335735-060
Décor Trim Panel, Black 335739-030
Décor Trim Panel, Cherry 335739-020
Décor Trim Panel, Maple 335739-010
