Infinity INTERMEZZO 1.2s - Electrical Parts List

Electrical Parts List
Part# Reference Designator Qty Description
Linear Amplifier/Regulator Board
Semiconductors
DS0001 D301,D302,D303,D304,D305, 24 RECT, 100mA 75V SIGNAL 1N4148T
D306, D307,D308,D309,D310,
D311,D312, D313,D314,D315,
D316,D317,D318, D319,D320,
D321,D323,D325,D330
DR0085 D324 1 RECT, 8A 400V TO220AC MUR860
QB0002 Q314,Q315,Q317 3 TRANS, NPN 40V .6A TO92 2N4401
QB0017 Q303,Q308,Q322,Q323 4 TRANS, NPN 150V 0.6A 2N5551TR
QB0018 Q302,Q304,Q309,Q313,Q316,Q324 6 TRANS, PNP 150V 0.6A 2N5401TR
QB0033 Q319 1 TRANS, NPN 250V 1A TO220 TIP47
QM0015 Q305,Q310,Q320,Q321 4 MOSFET, IRF640 TO220AB
QM0032 Q306,Q307,Q311,Q312 4 MOSFET, IRF9640 T0220AB
QM0035-S Q301 1 JFET, J111 SELECTED TR ONLY
UA0003 U306 1 OPAMP, QUAD 14PIN DIL LM324N
UA0009 U301 1 OPAMP, QUAD 14P DIL TL074/084
UF0013 U304 1 FOTO, 6PIN MOC3012
UP0004 U307 1 PWM, 8PIN DIL UC3842N
UV0007 U303 1 VREG, LINEAR TO220 LM7905CT
UV0013 U302 1 VREG, +5V 100MA TO220 LM7805CT
DZ0018 U305 1 ZENER, 2.5-37V SHUNT TL431CLP
DZ0002 Z303 1 ZENER, 500mW 12V 5% 1N5242B
DZ0021 Z301,Z302 2 ZENER, 500MW 15V 5% 1N5245B
DZ0034 Z304 1 ZENER, 500MW 10V 5% 1N5240B
Capacitors
CC0020 C335,C366 2 CAP, CA 470PF 100V 5%
CC0040 C313,C324,C331 3 CAP, CA 4700PF 100V 10%
CC0059 C311,C312,C322,C323,C372,C373 6 CAP, CA .1UF 100V 20%
CC0065 C337,C367 2 CAP, CA 2200P 100V 10%
CC0079 C343 1 CAP, C .1UF 50V 20% 5MMLS
CC0082 C350,C351,C370,C371 4 CAP, CA .1UF 50V 20%
CC0087 C332,C338 2 CAP, CA .01UF 100V 20%
CC0108 C307,C317 2 CAP, CA 22PF 50V 10
CE0018 C329,C330 2 CAP, E 100UF 25V 20% 5MMLS
CE0098 C301,C309,C310,C319,C320 5 CAP, E 22UF 50V 20% 5X11 5MMLS
CE0103 C348 1 CAP, E 100UF 35V 85DEG 5MMLS
CE0106 C305,C315,C326 3 CAP, E 22UF 35V BP 8X11 5MMLS
CF0008 C342 1 CAP, F 2200PF 100V 5% 5MMLS
CF0035 C306,C316 2 CAP, F .022UF 100V 5% 5MMLS
CF0045 C302,C303 2 CAP, F .1UF 63DC 5% 5MMLS
CC0032 C358 1 CAP, C 2200PF 600V 10% BULK
CC0017 C340 1 CAP, C 330PF 100V 10% 5MMLS BU
CC0021 C360,C362,C363 3 CAP, C 470PF 1KV 10% BULK
CC0072 C341 1 CAP, CA 100PF 100V 10%
CC0078 C344 1 CAP, C .22UF 50V 10% .2LS BULK
CC0095 C345,C347 2 CAP, C 470P 100V 5
CE0121 C355,C356 2 CAP, E 470UF 200V 20% 30X25
18
INTERMEZZO 1.2s
