Infinity Intermezzo 4.1t

INTERMEZZO 4.1t
13
1 Cabinet Intermezzo 4.1t L/R (Not for Sale)
2 Amplifier Assembly Not For Sale
3 Grille (L) (Set - Upper & Lower) Blue 335734-052
(R) (Set - Upper & Lower) Blue 335734-051
(L) (Set - Upper & Lower) Gray 335734-042
(R) (Set - Upper & Lower) Gray 335734-041
(L) (Set - Upper & Lower) Eggplant 335734-062
(R) (Set - Upper & Lower) Eggplant 335734-061
4 Side Trim Panels (L) (Set - Upper & Lower) (Black) 335280-032
(R) (Set - Upper & Lower) (Black) 335280-031
(L) (Set - Upper & Lower) (Cherry) 335280-022
(R) (Set - Upper & Lower) (Cherry) 335280-021
(L) (Set - Upper & Lower) (Maple) 335280-012
(R) (Set - Upper & Lower) (Maple) 335280-011
5 Front Baffle (R) 335274-001
(L) 335274-002
6 Low-Frequency Transducer 12" (305mm) C.M.M.D., cast frame, shielded 335036-001
DCR = 7.6 ohms ±10%
7 Midrange Frequency Transducer 3-1/2" (89mm) cone - C.M.M.D., 335224-001
magnetically shielded, neodymimum,
DCR = 4.8 ohms, ±10%
8 Mid-Bass Frequency Transducer 6-1/2" (165mm) cone - C.M.M.D., 335418-001
magnetically shielded, neodymimum,
DCR = 5.6 ohms, ±10%
9 High-Frequency Transducer 1" (25mm) C.M.M.D. Neodymium, Shielded 335225-002
DCR = 3.4 ohms ±10%
10 Mid/Twt Crossover Network 335287-002
11 Mid-Bass Crossover Network 335287-001
12 R.A.B.O.S. Control Assembly (R) 335457-003
(L) 335457-004
13 Grille Retainers (20) 333249-003
14 Woofer Trim Ring (R) 335450-001
(L) 335450-002
15 Trim Ring Grille Cup (2) 337039-001
16 Midrange Isolator Cup 335226-001
17 Isolator Cup Gasket 335705-001
18 Top/Bottom Housing Gasket 336527-001
19 Front Foot (R) 335451-001
(L) 335451-002
20 Rear Foot (2) 336217-001
21 Rubber Foot Pad (2) 335459-001
Mechanical Parts List
