INTERMEZZO 4.1t
Electrical Parts List
Part# Reference Designator Qty. Description
Feature PCB
Semiconductors
UA0003 U100, U101 2 OPAMP, QUAD 14PIN DIL LM324N
UA0009 U102, U103 2 OPAMP, QUAD 14P DIL TL074/084
UF0012 U104 1 FOTO, 6PIN 4N35
DR0038 D111, D112, D113, D114, D115, D116 6 RECT, 1A 400V GENERAL 1N4002
DS0001 D100, D101, D102, D103, D104, D105, D106, D107, D108, 17 RECT, 100mA 75V SIGNAL 1N4148T
D109, D110, D117, D118, D119, D120, D121, D122
DZ0013 Z100 1 ZENER, 500MW 5.6V 5% 1N5232B
QM0035-S Q100, Q101 2 JFET, J111 SELECTED TR ONLY
Resistors
RC0003 R159 1 RES, CF 1K0 1/4W 5%
RC0004 R144, R145 2 RES, CF 1M0 1/4W 5%
RC0006 R135, R136, R137, R138, R139, R140, R143, 12 RES, CF 10K 1/4W 5%
R152, R155, R157, R158, R160
RC0009 R161 1 RES, CF 10ohms1/4W 5%
RC0037 R142, R146 2 RES, CF 2K0 1/4W 5%
RC0039 R147, R148, R153, R156 4 RES, CF 2K2 1/4W 5%
RC0083 R111, R113, R141 3 RES, CF 100K 1/4W 5%
RC0115 R150 1 RES, CF 47K 1/4W 5%
RC0135 R151 1 RES, CF 150K 1/4W 5%
RC0192 R100 1 RES, CF 2K0 1/2W 5%
RC0273 R117, R121, R132 3 RES, ZERO OHM 1/4W
RC0277 R154 1 RES, CF 5M6 1/4W 5%
RC0281 R149 1 RES, CF 510K 1/4W 5%
RM0001 R112 1 RES, MF 1K00 1/4W 1%
RM0002 R106, R123, R124, R162 4 RES, MF 10K0 1/4W 1%
RM0011 R102, R103, R128 3 RES, MF 100K 1/4W 1%
RM0019 R127 1 RES, MF 1K30 1/4W 1%
RM0075 R133 1 RES, MF 475 ohms1/4W 1%
RM0078 R110 1 RES, MF 680 ohms1/4W 1%
RM0106 R107 1 RES, MF 14K0 1/4W 1%
RM0113 R122, R125 2 RES, MF 20K0 1/4W 1%
RM0115 R126 1 RES, MF 23K7 1/4W 1%
RM0142 R108 1 RES, MF 287K 1/4W 1%
RM0180 R104, R105 2 RES, MF 4K99 1/4W 1%
RM0193 R114, R115, R118, R119 4 RES, MF 42K2 1/4W 1%
RM0195 R130 1 RES, MF 187K 1/4W 1%
RM0269 R129 1 RES, MF 93K1 1/4W 1%
RM0290 R109 1 RES, MF 143K 1/4W 1%
RM0404 R101 1 RES, MF 54R9 1/4W 1%
Capacitors
CC0025 C121, C123 2 CAP, CA 1000PF 100V 10%
CC0072 C100, C101, C103, C119, C124 5 CAP, CA 100PF 100V NPO 10%
CC0082 C116, C120 2 CAP, CA .1UF 50V 20%
CC0087 C127 1 CAP, CA .01UF 100V 20%
CE0003 C117, C118 2 CAP, E 2.2UF 50V 20% 105C
CE0098 C106, C125, C126 3 CAP, E 22UF 50V 20% 5X11 5MMLS
CE0103 C122 1 CAP, E 100UF 35V 85DEG 5MMLS
