INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
CE0116 C102 1 CAP, E 2.2UF 50V BP 6X11 5MMLS
CF0045 C113, C114 2 CAP, F .1UF 63DC 5% 5MMLS
CF0088 C104, C105 2 CAP, F .01UF 100V 5% 5MMLS
CF0092 C107 1 CAP, F 1000PF 100V 5% 5MMLS
CF0118 C112 1 CAP, F .33UF 63V 10% 5MMLS
CF0125 C108, C110 2 CAP, F .068UF 100V 5% 5MMLS
CF0128 C109, C111 2 CAP, F .033UF 100V 5% 5MMLS
Miscellaneous
JC0049 J103 1 CNCTR, DUAL JACK RCA
JC0064 J104 1 CNCTR, DC POWER JACK 2MM DIA
JH0008 J100 1 CNCTR, HEADER 5PIN .100CTR
JH0074 J101, J102 2 CNCTR, HEADER 8PIN LOCKING .1C
MM0025 W100 1 MISC, PC MT SCREW TERM 6-32
MT0003 FO101 1 TERM, FASTON MALE PCMT 250X032
MT0023 FO100, FO102 2 TERM, FASTON MALE PCMT 187X032
MT0031 FO103 1 TERM, FASTON MALE PCMT 205X020
SR0040 S100 1 SWITCH, SLIDER DP3T PCB MOUNT
Linear PCB
Semiconductors
QB0033 Q319 1 TRANS, NPN 250V 1A TO220 TIP47
QM0015 Q305, Q310, Q320, Q321 4 MOSFET, IRF640 TO220AB
QM0032 Q306, Q307, Q311, Q312 4 MOSFET, IRF9640 T0220AB
QM0035-S Q301 1 JFET, J111 SELECTED TR ONLY
UV0007 U303 1 VREG, LINEAR TO220 LM7905CT
UV0013 U302 1 VREG, +5V 100MA TO220 LM7805CT
DR0088 D324 1 RECT, IR HEXFRED HFA08TB60
UA0003 U306 1 OPAMP, QUAD 14PIN DIL LM324N
UA0009 U301 1 OPAMP, QUAD 14P DIL TL074/084
UF0013 U304 1 FOTO, 6PIN MOC3012
UP0004 U307 1 PWM, 8PIN DIL UC3842N
DS0001 D301, D302, D303, D304, D305, D306, D307, D308, D309, 24 RECT, 100mA 75V SIGNAL 1N4148T
D310, D311, D312, D313, D314, D315, D316, D317, D318,
D319, D320, D321, D323, D325, D330
DZ0002 Z303 1 ZENER, 500mW 12V 5% 1N5242B
DZ0021 Z301, Z302 2 ZENER, 500MW 15V 5% 1N5245B
DZ0034 Z304 1 ZENER, 500MW 10V 5% 1N5240B
QB0002 Q314, Q315, Q317 3 TRANS, NPN 40V .6A TO92 2N4401
QB0017 Q303, Q308, Q322, Q323 4 TRANS, NPN 150V 0.6A 2N5551TR
QB0018 Q302, Q304, Q309, Q313, Q316, Q324 6 TRANS, PNP 150V 0.6A 2N5401TR
DZ0018 U305 1 ZENER, 2.5-37V SHUNT TL431CLP
Resistors
RC0004 R399 1 RES, CF 1M0 1/4W 5%
RC0005 R388 1 RES, CF 10K 1/2W 5%
RC0006 R310, R349 2 RES, CF 10K 1/4W 5%
RC0061 R350 1 RES, CF 4K7 1/4W 5%
RC0083 R303 1 RES, CF 100K 1/4W 5%
RC0087 R323, R326, R327, R339, R340, R341 6 RES, CF 330 ohms1/4W 5%
RC0116 R3107 1 RES, CF 330K 1/4W 5%
