Infinity Intermezzo 4.1t

11) After silicon sealer dries, reassemble feature PCB replacing all connectors and switch assembly.
Replace faceplate and all connectors; install amplifier back into the IM4.1t enclosure. Replace woofer.
12) Test the unit.
Model Serial number (120v) Status Action
Intermezzo 4.1t All Serial numbers affected
Distortion may be present at
low volume levels
Remove and re-wire R153, R154, D110
on the opposite side of the Feature PCB
INTERMEZZO 4.1t
19
