Infinity Kappa Series perfect 10 VQ User Manual

Infinity Systems • 250 Crossways Park Drive, Woodbury, NY 11797 USA
800.553.3332 • FAX 516.682.3523 • www.infinitysystems.com
© 2002 Harman International Industries, Incorporated • P/N:PERF10/12/dVQOM • Printed 11/02
Declaration of Conformity
We,Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
FRANCE
declare in own responsibility, that the products described in this
owner’s manual are in compliance with technical standards:
EN 50081-1:1992
EN 50082-1:1997
Emmanuel Millot
Harman Consumer International
Chateau-du-Loir, France. 11/02
THIELE AND SMALL PARAMETERS
Perfect10 VQ Perfect10d VQ Perfect12 VQ Perfect12d VQ
Diameter 10" (250mm) 10" (250mm) 12" (300mm) 12" (300mm)
Sensitivity @ 2.83V/1m 87dB 90dB 89dB 92dB
Power Handling 400W RMS/1600W Peak 400W RMS/1600W Peak 400W RMS/1600W Peak 400W RMS/1600W Peak
Frequency Response 25Hz – 400Hz 25Hz – 400Hz 23Hz – 400Hz 23Hz – 400Hz
Impedance per voice coil 4 ohms 4 ohms 4 ohms 4 ohms
Voice-Coil Diameter 3" (77mm) 3" (77mm) 3" (77mm) 3" (77mm)
Mounting Depth 6-1/2" (166mm) 6-1/2" (166mm) 7" (178mm) 7" (178mm)
Overall Diameter 10-1/2" (267mm) 10-1/2" (267mm) 12-3/8" (315mm) 12-3/8" (315mm)
Cut-Out Diameter 9-5/16" (237mm) 9-5/16" (237mm) 10-7/8" (277mm) 10-7/8" (277mm)
Basket Displacement .072 ft^3 (2.04 L) .072 ft^3 (2.04 L) .108 ft^3 (3.06 L) .108 ft^3 (3.06 L)
Voice-Coil DC Resistance Revc 3.32 ohms 1.66 ohms 3.42 ohms 1.66 ohms
Voice-Coil Inductance Levc 1.2mH .8mH 1.14mH .81mH
Driver Radiating Area Sd .344 ft
2
(.0323M^2) .344 ft
2
(.0323M^2) .441 ft
2
(.0491M^2) .441 ft
2
(.0491M^2)
Motor Force Factor BL w/LowQ Insert 15.05 11.5532 15.55 11.86
w/MidQ Insert 13.05 9.33 12.19 9.6
w/No Insert 10.49 8.1 9.67 8.28
Compliance Volume Vas 1.61 ft
3
(45.88 L) 1.32 ft
3
(37.65 L) 3.38 ft
3
(96.43 L) 3.31 ft
3
(94.28 L)
Suspension Compliance Cmd 309.68uM/N 254.13uM/N 281.68uM/N 275.39uM/N
Moving Mass, Air Load Mms 153.44g 157.9g 182.7g 189.8g
Moving Mass, Diaphragm Mmd 150.1g 154.56g 176.44g 183.54g
Free-Air Resonance Fs 23.09Hz 25.13Hz 22.19Hz 22.01Hz
Mechanical Q Qms 9.67 10.24 10.29 10.52
Electrical Q Qes w/LowQ Insert .33 .31 .36 .31
w/MidQ Insert .44 .46 .5 .47
w/No Insert .68 .61 .79 .64
Total Q Qts w/LowQ Insert .32 .30 .34 .30
w/MidQ Insert .42 .44 .47 .46
w/No Insert .63 .57 .74 .60
Magnetic-Gap Height Hag 3/8" (10mm) 3/8" (10mm) 3/8" (10mm) 3/8" (10mm)
Voice-Coil Height Hvc 1-11/16" (43.5mm) 1-11/16" (43.5mm) 1-11/16" (43.5mm) 1-11/16" (43.5mm)
Maximum One-Way Linear Excursion Xmax 11/16" (16.75mm) 11/16" (16.75mm) 11/16" (16.75mm) 11/16" (16.75mm)
A valid serial number is required for warranty coverage.

Infinity Kappa Series perfect 10 VQ Specifications

General

Brand	Infinity
Model	Kappa Series perfect 10 VQ
Category	Subwoofer
Language	English
