InfiRay AFFO AP13 User Manual

Charging
The AFFO series is supplied with a built-in rechargeable
Li-ion battery pack, which allows operation up to 9.5
hours. When using the device for the first time, please
fully charge it first.
l Open the USB rubber cap (10) on the bottom of the
device.
l Connect the Type C plug of the data cable to the Type
C port (12) on the device.
l Connect anther port of the data cable to the power
adapter.
l Insert the plug of the adapter to the 110-240V socket.
l When the device is charging, the power indicator (11)
next to the Type C port (12) is red. The power indicator
(11) is on only in the charging status. When the power
indicator (11) turns green, the device is fully charged.
When the power indicator (11) blinks alternately red and
green, it indicates that the battery is not charged or the
temperature is too high or too low.
l When charging, a lighting icon will appear inside the
battery icon on the display. The lighting icon will not
disappear until the data cable is removed or the power
is cut off.
l Charging is finished when the interior of the battery icon
on the display is completely green .
l During using, when the battery icon turns red , this
means the power level is low, please charge the device
in time to avoid the data loss.
7
ENGLISH
Button
Current
status
Short press
Long press
Down
button
Home screen
Take a photo
Start the video
recording
Main menu
interface
Scroll down
the menu
option
- -
Video
recording
Take a photo
Stop and save
the video
recording
Up + M
buttons
Home screen
- -
Turn on/off the
stadiametric
rangefinder
function
Up +
Down
buttons
Home screen
- -
Turn on/off
hotspot
tracking
M + Down
buttons
Home screen
- -
Calibration the
sensor
6 ENGLISH

InfiRay AFFO AP13 Specifications

General

Brand	InfiRay
Model	AFFO AP13
Category	Monocular
Language	English
