InfiRay Xtherm II Series User Manual

XthermⅡSeries Thermal Imaging Camera for Smartphone User manual
Version: V1.00 7
Appendix3 Controlling protocol
Controlling protocol is the Zoom (Absolute) of UVC protocol. Controlling
command is 2 bytes in total, the low-byte is parameter, the high-byte is register
address.
For example: shutter working commend 0x8000.
Detailed commands:
Table2 Controlling commands
NO.
Register
address
Parameter
Description
1
0x80
0x00
Shutter NUC
2
0x01
Background NUC
3
0x02
Detector original value output
4
0x05
Image data output
5
0x20
Normal temperature range
6
0x21
High temperature range
7
0x27
16 byte parallel image data output
8
0x28
8 byte parallel image data output
9
0x29
16 byte parallel image data and
temperature data output
10
0x30
8 byte parallel image data and
