InFocus IN124A User Manual

11
Shutting down the projector
Auto Off Time
The projector also has an Auto Off Time feature that automatically turns the projector off
after no active sources are detected and no user interaction with the projector is performed
for 30 minutes. By default, this feature is off. You can change the length of time, see
page 29.
Turning off the projector
To turn the projector off, press the Power button on the remote or keypad. The lamp turns
off and the Power LED blinks blue for 30 seconds while the fans continue to run to cool the
lamp. If the Power Saving Mode feature is on and when the lamp has cooled, the LED lights
blue and the fans stop. If the Power Saving Mode feature is off and when the lamp has cooled,
the LED blinks blue and the fans stop. Unplug the power cable to completely power off the
projector.
Troubleshooting your setup
If your image appears correctly on the screen, skip to the next section. If it does not,
troubleshoot the setup.
The Status Indicator Lights on top of the projector indicates the state of the projector and
can help you troubleshoot
.
Table 3: Indicator Lights
Status Indicator Light Meaning
POWER: Solid Blue
TEMP: Off
LAMP: Off
POWER: Blinking Blue
TEMP: Off
LAMP: Off
1. If the Power Saving Mode feature is on,
the projector is plugged in.
2. The projector is on and initialized.
3. The projector is in normal operation.
1. If the Power Saving Mode is off, the
projector is plugged in.
2. The projector is powering down and
the fans are cooling the projector.
POWER: Blinking blue
TEMP: Blinking red
LAMP: Blinking red
POWER: Solid blue
TEMP: Blinking red
LAMP: Blinking red
The projector fan(s) are not operating
correctly and the projector has been shut
down.
The lamp failed to ignite.
Contact Technical Support if the problem
persists. Visit www.infocus.com/support
to contact service.
POWER: Solid blue
TEMP: Blinking red
LAMP: Blinking red
The lamp has reached its end of life and
must be replaced. The lamp will continue
to operate until it fails.
Contact Technical Support. Repair may be
needed.
POWER: Solid blue
TEMP: Blinking blue
LAMP: Blinking blue
1. The projector is overheating and the
lamp will be shut off. The fans will
continue to run.
2. The projector will not turn back on
until the cooling process is complete.

InFocus IN124A Specifications

General

Matrix size	0.55 \
Number of colors	134 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	15000:1
Screen size compatibility	- \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-40 - 40 °
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	24 kHz
Horizontal synchronization (max)	91 kHz
Horizontal synchronization (min)	15 kHz
Projector brightness (economic mode)	3200 ANSI lumens
Focus	Manual
Throw ratio	1.9 - 2.2:1
Zoom capability	Yes
Focal length range	- mm
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	190 W
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Full HD	No
Supported video modes	1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
HDMI version	1.4
Audio (L/R) in	0
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Optical disc player type	Not included
Internal storage capacity	2 GB
HDCP	-
Noise level	32 dB
Preset modes	Bright, Presentation
Certification	UL, c-UL (US/Canada), FCC (US/Canada), CE
Noise level (economic mode)	30 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR
RMS rated power	2 W
Audio formats supported	AAC, ADPCM, MP1, MP2, MP3, OGG, WMA
Image formats supported	BMP, JPG
Video formats supported	H.263, H.264, M-JPEG, MPEG1, MPEG4, WMV, XVID
Document formats supported	PDF
Placement	Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	- W
Operating altitude	0 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Cables included	VGA
Remote control type	IR

Weight and Dimensions

Depth	220 mm
Width	292 mm
Height	108 mm
Weight	3170 g
Package depth	305 mm
Package width	362 mm
Package height	197 mm
Package weight	3670 g
