26
Advanced Menu
Image:
3D Control:
3D: allows you to enjoy 3D (stereoscopic) content. Your projector supports Auto,
Top-Bottom, Frame Sequential, Frame Packing, Side-by-Side for controlling LCD shut
-
ter glasses. In addition to the projector, you will need a pair of 3D shutter glasses, 3D
content, and 3D compatible source. Ensure the glasses you choose are consistent with
the synchronization mode you will be using.
3D Sync Invert: If the image appears to flutter, look odd or if the image depth looks off
or you experience eye strain, turn this feature on to see if the image improves.
Color
Color: adjusts a video image from black and white to fully saturated color. The color
setting applies to video sources only.
Red/Green/Blue Gain: adjusts the gain of the red, green or blue channel of the image.
Red/Green/Blue Offset: adjusts the offset of the red, green or blue channel of the
image.
Color Space: applies to computer and component video sources. It allows you to
select a color space that has been specifically tuned for the input signal. When Auto is
selected, the projector automatically determines the standard. To choose a different
setting, turn off Auto, then choose RGB for computer sources or choose either
REC709 or REC601 for component video sources.
Color Temperature: changes the intensity of the colors. Select a listed relative
warmth value.
Gamma: select the appropriate gamma from among Video, Film, Bright, and CRT.
Tint: adjusts the red-green color balance in the image of NTSC video images. The tint
setting applies to NTSC video sources only.
White Intensity: increases the brightness of whites that are near 100%.
PC:
Force Wide: when this is off, the analog locking algorithms choose the standard mode
resolution (4:3) as the preferred default resolution. When this is on, the analog locking
algorithms choose wide mode resolution (16:10) as the preferred default resolution.
Phase: adjusts the horizontal phase of a computer source.
Prevent PC Screen Saver: prevents your computer from going into Screen Save
mode. The projector must be connected to the PC via a USB cable for this feature to
work.
Sync Threshold: (progressive signals only) If a hardware device, such as a DVD player,
is not syncing properly with the projector, select this option to help it to sync when
connected to the projector.
Tracking: adjusts the vertical scan of a computer source.
Horizontal/Vertical Position: adjusts the position of a computer source.
Video:
Detect Film: determines whether the original source of the input video was film (pro-
gressive) or video (interlaced).
Overscan: removes noise around the video image.
Set Black Level: analyzes the current input image and calculates an offset value which
is then added to the analog to digital converter black level value. This ensures optimum
black level for each analog source.
Setup
Status/Service
Basic Menu
3D Control...
Color...
PC...
Video...
( Advanced Menu )
MDL: IN124a
FW: 1.12
Advanced Menu

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN124A and is the answer not in the manual?

InFocus IN124A Specifications

General IconGeneral
Matrix size0.55 \
Number of colors134 million colors
Native aspect ratio4:3
Projection distance- m
Projection technologyDLP
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)15000:1
Screen size compatibility- \
Projector native resolutionXGA (1024x768)
Keystone correction, vertical-40 - 40 °
Vertical synchronization (max)120 kHz
Vertical synchronization (min)24 kHz
Horizontal synchronization (max)91 kHz
Horizontal synchronization (min)15 kHz
Projector brightness (economic mode)3200 ANSI lumens
FocusManual
Throw ratio1.9 - 2.2:1
Zoom capabilityYes
Focal length range- mm
Lamp power240 W
Lamps quantity1 lamp(s)
Light source typeLamp
Lamp power (economic mode)190 W
Service life of light source3500 h
Service life of light source (economic mode)5000 h
Full HDNo
Supported video modes1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
HDMI version1.4
Audio (L/R) in0
USB connector typeMini-USB B, USB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity3
Optical disc player typeNot included
Internal storage capacity2 GB
HDCP-
Noise level32 dB
Preset modesBright, Presentation
CertificationUL, c-UL (US/Canada), FCC (US/Canada), CE
Noise level (economic mode)30 dB
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR
RMS rated power2 W
Audio formats supportedAAC, ADPCM, MP1, MP2, MP3, OGG, WMA
Image formats supportedBMP, JPG
Video formats supportedH.263, H.264, M-JPEG, MPEG1, MPEG4, WMV, XVID
Document formats supportedPDF
PlacementCeiling
Product typeStandard throw projector
Product colorBlack
Market positioningPortable
Cable lock slot typeKensington
Power sourceAC
Power consumption (standby)- W
Operating altitude0 - 3048 m
Operating temperature (T-T)0 - 40 °C
Cables includedVGA
Remote control typeIR
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width292 mm
Height108 mm
Weight3170 g
Package depth305 mm
Package width362 mm
Package height197 mm
Package weight3670 g
