8
Displaying an image
Press the Power button.
The Power LED lights blue, and the fans start to run. When the lamp comes on, the start up
screen displays. It can take up to a minute for the image to achieve full brightness. Note:
When the feature, AC Power On, is enabled, the projector automatically turns on when
power is connected. This allows control of ceiling mounted projectors with a wall power
switch.
No start up screen? Get help on page 12.
Turn on your computer or video device.
The image should appear on the projection screen. If it doesn’t, press the Source button on
the projector’s keypad or remote.
If you are using a VGA cable to connect your computer to the projector:
If using a laptop, make sure its external video port is active.
Many laptops do not automatically turn on their external video port when a projector is
connected. Usually a key combination like FN + F8 or CRT/LCD key turns the external
display on and off. Locate a function key labeled CRT/LCD or a function key with a monitor
symbol. Press FN and the labeled function key simultaneously.
Refer to your laptop's documentation for more information about your laptop's
key combination.
No laptop image? Try pressing the Auto Image button on the remote. Get help on
page 12.
press Power button
turn on computer or
video device
activate laptop’s external port
monitor key or
LCD/CRT key
FN key

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN124A and is the answer not in the manual?

InFocus IN124A Specifications

General IconGeneral
Matrix size0.55 \
Number of colors134 million colors
Native aspect ratio4:3
Projection distance- m
Projection technologyDLP
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)15000:1
Screen size compatibility- \
Projector native resolutionXGA (1024x768)
Keystone correction, vertical-40 - 40 °
Vertical synchronization (max)120 kHz
Vertical synchronization (min)24 kHz
Horizontal synchronization (max)91 kHz
Horizontal synchronization (min)15 kHz
Projector brightness (economic mode)3200 ANSI lumens
FocusManual
Throw ratio1.9 - 2.2:1
Zoom capabilityYes
Focal length range- mm
Lamp power240 W
Lamps quantity1 lamp(s)
Light source typeLamp
Lamp power (economic mode)190 W
Service life of light source3500 h
Service life of light source (economic mode)5000 h
Full HDNo
Supported video modes1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
HDMI version1.4
Audio (L/R) in0
USB connector typeMini-USB B, USB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity3
Optical disc player typeNot included
Internal storage capacity2 GB
HDCP-
Noise level32 dB
Preset modesBright, Presentation
CertificationUL, c-UL (US/Canada), FCC (US/Canada), CE
Noise level (economic mode)30 dB
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR
RMS rated power2 W
Audio formats supportedAAC, ADPCM, MP1, MP2, MP3, OGG, WMA
Image formats supportedBMP, JPG
Video formats supportedH.263, H.264, M-JPEG, MPEG1, MPEG4, WMV, XVID
Document formats supportedPDF
PlacementCeiling
Product typeStandard throw projector
Product colorBlack
Market positioningPortable
Cable lock slot typeKensington
Power sourceAC
Power consumption (standby)- W
Operating altitude0 - 3048 m
Operating temperature (T-T)0 - 40 °C
Cables includedVGA
Remote control typeIR
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width292 mm
Height108 mm
Weight3170 g
Package depth305 mm
Package width362 mm
Package height197 mm
Package weight3670 g
