InFocus INL4129 - RS232 Protocol Functions - Source, Aspect, Volume, Mute

English
55
ADDITIONAL INFORMATION
Blank Key (AV Mute) return code (ok)
ON & return (BLK1!)
(0-1,1)
OFF & return (BLK0!) (0-1,0)
Source return code (ok)
Status ? (SRC?)
(0-22,n) n=0-22
Computer1 (VGA IN 1) (SRC0)
Computer2 (VGA IN 2) (SRC1)
VIDEO (SRC11)
S-VIDEO (SRC12)
HDMI1 (SRC4)
HDMI2 (SRC5)
HDBaseT (SRC17)
Computer1 (VGA IN 1) & return (SRC0!) (0-22,0)
Computer2 (VGA IN 2) & return (SRC1!) (0-22,1)
VIDEO & return (SRC11!) (0-22,11)
S-VIDEO & return (SRC12!) (0-22,12)
HDMI1 & return (SRC4!) (0-22,4)
HDMI2 & return (SRC5!) (0-22,5)
HDBaseT & return (SRC17!) (0-22,17)
Aspect return code (ok)
Status ? (ARZ?)
(0-6,n) n=0,1,2,3,4,6
Auto (ARZ0)
Native (ARZ1)
4 X 3 (ARZ2)
16 X 9 (ARZ3)
Letterbox (ARZ4)
16 X 10 (ARZ6)
Auto & return (ARZ0!) (0-6,0)
Native & return (ARZ1!) (0-6,1)
4 X 3 & return (ARZ2!) (0-6,2)
16 X 9 & return (ARZ3!) (0-6,3)
Letterbox & return (ARZ4!) (0-6,4)
16 X 10 & return (ARZ6!) (0-6,6)
Volume return code (ok)
Status ? (VOL?) (0-10,nn) n=0~10
volume + (VOL+)
volume - (VOL-)
Set volume (VOLnn) n=0 ~ 10
volume + & return (VOL+!) (0-10,nn) n=0~10
volume - & return (VOL-!) (0-10,nn) n=0~10
Set volume & return (VOLnn!) n=0 ~ 10 (0-10,nn) n=0~10
Mute return code (ok)
Status ? (MTE?)
(0-1,n) n=0,1
ON (MTE1)
OFF (MTE0)
ON & return (MTE1!)
(0-1,1)
OFF & return (MTE0!) (0-1,0)
Firmwave Version return code (ok)
Status ? (FVS?) (nnnn) n=x.x.xx
