INTRODUCTION
Connections
7
621 3 4 5
8
10111213 16
9
1514
No Item No Item
1. HDMI 2 (v1.4) Connector 9. Audio In 2 Connector
2.
HDMI 1 (v2.0)(4K) Connector
10.
VGA Out Connector
3. USB Power Out (5V 1.5A)
Connector
11. RS232 Connector
4. VGA In 1 Connector 12. RJ-45 Connector
5. Composite Connector 13. Power Socket
6. Audio In 1 / Microphone Connector 14. VGA In 2 Connector
7. Kensington
TM
Lock Port 15. S-Video Connector
8. Audio Out Connector 16. HDBaseT Connector
