InFocus Learn Big XS1 Reference Guide

Introduction 7
Remote control
1. Power
Toggles the projector on or off.
See "Starting up the projector" on
page 22 and "Shutting down the
projector" on page 42 for details.
2. FREEZE
Freezes the projected image. See
"Freezing the image" on page 39 for
details.
3. Left
When the On-Screen Display (OSD)
menu is activated, the #3, #7 and #9
buttons are used as directional arrows
to select the desired menu items and
to make adjustments. See "Using the
menus" on page 23 for details.
4. BLANK
Used to hide the screen image. See
"Hiding the image" on page 40 for
details.
5. Digital Zoom buttons (+, -)
Magnifies or reduces the projected
image size. See "Magnifying and
searching for details on the projected
picture" on page 31 for details.
6. Menu/Exit
Turns on the On-Screen Display
(OSD) menu. Exits and saves menu
settings. See "Using the menus" on
page 23 for details.
7. Keystone buttons ( Up/ ,
Down/ )
Manually corrects distorted images
resulting from an angled projection.
See "Correcting keystone" on page 30
for details.
8. AUTO
Automatically determines the best
picture timings for the displayed
image. See "Auto-adjusting the image"
on page 29 for details.
9. Right/
Activates panel key lock. See "Panel
Key Lock" on page 47 for details.
10. SOURCE
Displays the source selection bar. See
"Switching input signal" on page 27 for
details.
11. Mode/Enter
Depending upon which input signal is
selected, selects an available picture
setup mode. See "Selecting a picture
mode" on page 33 for details.
Enacts the selected On-Screen
Display (OSD) menu item. See "Using
the menus" on page 23 for details.
1
4
9
7
8
6
10
2
3
5
7
11
I
I
