CD1-k – User Guide
Chapter 3 - Functional features
3 - ADDRESSING SWITCH / SPEED SELECTION
Each amplifier of the network must be configured with one single address.
A DIP8 switch accessible to the operator allows the configuration of the amplifier address as well as of the of the
CANopen bus communication speed.
• Addressing (6 selection bits)
Status of the cursors Address
6 5 4 3 2 1
OFF OFF OFF OFF OFF OFF 0
OFF OFF OFF OFF OFF ON 1
OFF OFF OFF OFF ON ON 3
... ... ... ... ... ... ...
ON ON ON ON ON ON 63
• Communication speed (2 selection bits)
Status of the cursors Speed
8 7
OFF OFF 1Mbits
OFF ON 500Kbits
ON OFF 250Kbits
ON ON 125Kbits
Note
:
- Address 00 must only be used in Local mode.
- An address ≠ 00 is used in Remote mode (use of the CANopen bus).
