22
ORIG, SG, SE: REMOTE STOP FAILURE
= REMOTE START BUTTON IS PRESSED WHILE REMOTE STOP CONTACT IS STILL OPEN.
ORIGINAL INTELLISYS CONTROLLER
SG INTELLISYS CONTROLLER
MEASURE VOLTAGE
BETWEEN BTS2-6 AND BTS2-7
IS THE VOLTAGE 0VDC?
YES. TRY REMOTE START AGAIN.
IF ALARM STILL OCCURS, SUSPECT PROBLEM
WITH RIBBON CABLE OR CONTROLLER FOR THE
ORIGINAL INTELLISYS CONTROLLER OR JUST THE
CONTROLLER FOR THE SG.
MEASURE VOLTAGE
BETWEEN P3 TERMINAL 19 & 20
NO. SUSPECT REMOTE STOP CONTACT IS STILL OPEN.
CORRECT PROBLEM AND TRY AGAIN. TO SIMULATE A CLOSED STOP CONTACT,
INSTALL A TEMPORARY JUMPER BETWEEN THE TERMINALS LISTED ABOVE.
SE INTELLISYS CONTROLLER
MEASURE VOLTAGE
BETWEEN J1 TERMINAL 3 & 4
