Ingersoll-Rand SL90 User Manual

64 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

80448574

Revision A

May 2015

Save These Instructions

Oil-Free Rotary Screw Air Compressor

Installation, Operation and Maintenance

SL90, SM90, SH90, SL110, SM110, SH110

SL132, SM132, SH132, SL150, SM150, SH150

SL200, SM200, SH200, SL250, SM250, SH250, SH300

L125, H125, HH125, L150, H150, HH150

L200, H200, HH200, L250, H250, HH250

L300, H300, HH300, L350, H350, HH350, HH400

61115.10.33

Table of Contents

Questions and Answers:

V
Virginia RushAug 13, 2025
How to troubleshoot low system air pressure in Ingersoll-Rand Air Compressor?
- E
  Eileen DuncanAug 14, 2025
  If the Ingersoll-Rand Air Compressor experiences low system air pressure, first press the “LOAD” button and then the “UNLOADED STOP” button. If this doesn't resolve the issue, access the options screen to set the offline pressure to a higher value. Also, check the air piping system for leaks and ensure manual condensate valves are closed and solenoid-operated condensate valves are not stuck open.
E
elloydAug 17, 2025
Why my Ingersoll-Rand Air Compressor fails to start?
- K
  kimmcknightAug 17, 2025
  If your Ingersoll-Rand Air Compressor fails to start, check the fuse, transformers, and wiring connections to ensure 110/120V control voltage is available. Also, ensure the emergency stop is disengaged by rotating the emergency stop button and pressing the reset button twice. Inspect starter auxiliary contacts, connections, wiring, and contactors, replacing if defective. Manually reset the main (or fan) motor overload relay and press the reset button twice.
R
Ronald NicholsonAug 21, 2025
What to do if Ingersoll-Rand SL90 fails to load?
- H
  Harry JohnsonAug 21, 2025
  If the Ingersoll-Rand Air Compressor fails to load, it could be due to leaking seals in the hydraulic cylinder. If the cylinder does not fully stroke when the “LOAD” button is pressed, overhaul the hydraulic cylinder. Alternatively, a defective load solenoid valve could be the cause. To check, remove the tube that runs from the load solenoid valve to the hydraulic cylinder, start the compressor, and press the “LOAD” button. If oil does not come out of the solenoid valve, replace it.
R
rthomasAug 25, 2025
What to do if Ingersoll-Rand SL90 shuts down due to high 2nd stage temperature?
- S
  Steven JohnsonAug 26, 2025
  If the Ingersoll-Rand Air Compressor shuts down due to high 2nd stage temperature, ensure the installation area has adequate ventilation and clean the fan side of the intercooler if it's dirty or plugged.
R
Rebekah PhillipsAug 28, 2025
How to fix water in Ingersoll-Rand SL90 system?
- G
  Geoffrey McdanielAug 28, 2025
  If there's water in the Ingersoll-Rand Air Compressor system, inspect and clean the moisture separator/drain trap, replacing it if defective. Also inspect and clean the trap drain or drain piping if plugged and inspect and clean the aftercooler core if dirty. Ensure enclosure panels are in place and the drain line slopes away from the trap, with a drip leg installed.
R
Robert ZimmermanSep 1, 2025
What causes excessive noise level in Ingersoll-Rand SL90 Air Compressor?
- C
  Caleb ConnerSep 1, 2025
  If the Ingersoll-Rand Air Compressor is producing excessive noise, contact an authorized distributor immediately and do not operate the unit, as this could indicate a compressor defect such as bearing, gear failure, or rotor contact. Ensure enclosure panels are in place and inspect and tighten any loose component mountings.
C
Christopher RyanSep 4, 2025
Why pressure relief valve opens on Ingersoll-Rand SL90?
- H
  Hannah Nguyen DDSSep 5, 2025
  If the pressure relief valve opens on the Ingersoll-Rand Air Compressor, adjust the controller set points if the compressor is operating over pressure. If the valve is defective, replace it.
J
Jon KellerSep 9, 2025
What causes excessive vibration in Ingersoll-Rand Air Compressor?
- C
  Cory HawkinsSep 9, 2025
  If the Ingersoll-Rand Air Compressor is experiencing excessive vibration, inspect and tighten any loose components. Contact an authorized distributor immediately and do not operate the unit if there is motor or compressor bearing failure. Inspect the area for other equipment that may be causing external vibrations.

Ingersoll-Rand SL90 Specifications

General

Brand	Ingersoll-Rand
Model	SL90
Category	Air Compressor
Language	English

Summary

GENERAL INFORMATION

General Operation and System Components

Covers compressor overview, air system, condensate, and lubrication.

Design Parameters and Control Options

Details pressures, temperatures, cooling, electrical, and capacity control.

Advanced Operational Features

Explains automatic start/stop, remote control, and scheduled operations.

INSTALLATION

Site Selection and Piping

Guidelines for plant location, discharge piping, and condensate management.

Pre-Start Checks and Connections

Essential electrical, water piping, and system venting procedures before startup.

Motor and System Checks

Procedures for checking motor rotation, water quality, and draining the system.

OPERATING INSTRUCTIONS

Controller Interface and Basic Operation

Covers basic operation, starting, stopping, emergency stops, and controller keys/interface.

Navigation and Display Features

Explains display layout, folder navigation, page navigation, and dashboard elements.

System Status and Event Logging

Details dashboard status, event logs, trip history, and event types.

Data Visualization and Maintenance Utilities

Covers graphing, performance logs, inspection logs, and maintenance scheduling.

Network, Web Access, and Security

Covers connecting to PC, Ethernet config, login, web access, and user/account management.

MAINTENANCE

Routine Maintenance and Safety Precautions

Overview of periodic tasks, safety, and service chart.

Component Service Procedures

Details for changing filters, oil, seals, and servicing bearings.

Lubrication and Filter Specifications

Information on motor bearing lubrication and pre-filter service.

TROUBLESHOOTING

Starting and Shutdown Issues

Remedies for compressor failures to start or unexpected shutdowns.

Pressure and Load Problems

Diagnosing and resolving low system pressure and loading issues.

Operational Anomalies and Faults

Troubleshooting excessive noise, vibration, and pressure relief valve activation.
