INK+IVY LANCASTER - Step 2: Attach Leg Frames and Metal Bracket; Step 3: Attach Leg Frame to Table Top

Page 2 of 3
(H3)x8
(H4)x8
(H5)x8
(H7)x1
Bolts Ø5/16"x25mm
Lock Washers Ø5/16"
Flat Washers Ø5/16"x19mm
Allen Key 4mm
Step 2: Attach the Half Leg Frame (P4) to Leg Frame (P3) and then assembly the Connecting Metal Bracket (H6) as
shown below.
(H1)x4
(H4)x4
(H5)x4
(H7)x1
Bolts Ø5/16"x75mm
Lock Washers Ø5/16"
Flat Washers Ø5/16"x19mm
Allen Key 4mm
Dining Height
Step 3: Attach the assembled leg frame to assembled table top as shown below for Dining Table
P4P3
H6
H5
H4
H3
H7
H5
H4
H1
H7
P4
* Please follow step 1, 2, 3 for Dining Table Assembly.
