Innovative Technology BV50 - 2 Environment and Power Requirements

3
Copyright Innovative Technology Ltd 2014 GA717-3
BV100 Operations Manual
2 ENVIRONMENT AND POWER REQUIREMENTS
ENVIRONMENT
POWER REQUIREMENTS
Table 2 – Power Requirements
Table 3 – Interface Logic Levels
Environment
Minimum
Maximum
Temperature
+3ºC (37F)
+50ºC (122F)
Humidity
5%
95% Non condensing
Table 1 – Environmental Requirements
Electrical Supply
Minimum
Maximum
Supply Voltage (V DC) Absolute
Limits
+11 V
+13.5 V
Supply Ripple Voltage
0 V
0.25 V @ 100 Hz
Supply Currents:
Sleep (low power mode)
TBC
Standby
0.4 A
Validating
1.5 A
Peak (Motor Stall)
3.0 A
Interface Logic Levels
Logic Low
Logic High
Inputs
0 V to + 0.5 V
+3.7 V + 12 V
Outputs with 2K2 pull up
0.6 V
Pull up voltage of host interface
Maximum Current Sink
50mA per output
