SMART HOPPER OPERATIONS MANUAL
22
22
APPENDIX D – EXAMPLE eSSP COMMUNICATIONS
For more details on generating the encryption key, refer to the SSP Protocol specification,
document number GA138
Host
Slave
Comments
> SYNC
< OK
> SET_GENERATOR, [64 bit prime
number]
< OK
Set the encryption key generator
> SET_MODULUS, [64 bit prime
number]
< OK
Set the encryption key modulus
> REQUEST_KEY_EXCHANGE, [64
bit host intermediate key]
< OK, [64bit slave intermediate key]
Host sends the host intermediate
key, the slave responds with the
slave intermediate key. The
encryption key is then calculated
independently by both the host and
the slave.
> GET_SERIAL
< OK < [SERIAL NUMBER]
> GET_DEVICE_SETUP
< OK < [SETUP INFORMATION]
> GET_COIN_AMOUNT, 0A 00 00 00
< OK < 2c 01
300 coins of 0010 value
> GET_COIN_AMOUNT, 14 00 00 00
< OK < 00 96
150 coins of 0020 value
> SET_ROUTING, 01 0A 00 00 00
< OK
Route coins of value 0010 to the
cash box
> SET_ROUTING, 00 14 00 00 00
< OK
Recycle coins of value 0020 for
future payouts
> SET_COIN_ACCEPT_INHIBIT, 00
01 00
< OK
Set the coin mech to Inhibit the
acceptance of coins of value 0001
> SET_COIN_ACCEPT_INHIBIT, 01
14 00
< OK
Set the coin mech to accept coins
of value 0020
> ENABLE
< OK
> POLL
< OK
> POLL
< OK
> POLL
< OK, COIN_CREDIT, 0100
Credit from coin mech of 0100
value
> POLL
< OK
> POLL
< OK, COIN_CREDIT, 0050
Credit from coin mech of 0050
value
> POLL
< OK
> PAYOUT_AMOUNT, 28 00 00 00
< OK
Payout a value of 0040
> POLL
< OK < DISPENSING, 14 00 00 00
Currently dispensed 0020
> POLL
< OK < DISPENSED, 28 00 00 00
Dispense value of 0040 completed
> POLL
< OK
Table 11 - eSSP example for the SMART hopper with coin mech connected via the hopper
