SMART HOPPER OPERATIONS MANUAL
6
2 TECHNICAL SPECIFICATION
ENVIRONMENT
Environment
Minimum
Maximum
Temperature
+3
o
C
+50
o
C
Humidity
5%
95% Non condensing
Table 1 - Environmental Requirements
POWER REQUIREMENTS
Electrical Supply
Minimum
Maximum
Supply Voltage (V DC)
Absolute Limits
+21.6 V
+26.4 V
Supply Ripple Voltage
0 V
0.25 V @ 100 Hz
Supply Currents
Standby
200 mA
Running
3 A
Peak (Motor Stall)
6.5 A
Table 2 - Power Requirements
Interface Logic Levels
Logic Low
Logic High
Inputs
0V to +0.5V
+3.7V to +12V
Outputs with 2K2 pull up
0.6V
Pull up voltage of host interface
Maximum Current Sink
50mA per output
Table 3 - Interface Logic Levels
COIN DIMENSIONS
Coin Parameter
Minimum
Maximum
Diameter
18mm
28.5mm
Thickness
1.65mm
3.3mm
Table 4 - Maximum and Minimum Coin Dimensions
CAPACITY
The capacity of the SMART Hopper depends on the size of coins. The table below shows
approximate capacity for various coins and assumes all the coins within the hopper are the
same type
Coin Type
Diameter
Thickness
Approximate Capacity
UK £1
22.5mm
3.15mm
1300
UK £2
28.4mm
2.5mm
800
Euro €1
23.25mm
2.33mm
1500
Table 5 - Approximate Hopper Capacities
WEIGHT
Coin Type
Coin Weight
Total Weight
Empty
-
2.60 Kg
UK £1
9.5g
Approximately 14.95Kg when full (1300 Coins)
UK £2
12.0g
Approximately 12.20Kg when full (800 Coins)
Euro €1
7.5g
Approximately 13.85Kg when full (1500 Coins)
Table 6 - SMART Hopper Weights
