8
DC power cable
(BA-306)
AC power supply
(BA-501)
Single battery (BA-500)
and double battery (BA-516)
10. A green light will ash each time a
breath is detected. Make certain that
the nasal cannula is properly aligned on
your face and you are breathing through
your nose.
Power Supply Options
Single and Double Rechargeable
Lithium Ion Batteries
The battery will power the Inogen One® G5
without connection to an external power
source. When fully charged, a single battery
will provide up to 4.5 hours of operation; a
double battery will provide up to 9 hours of
operation. The battery recharges when
properly installed in the Inogen One® G5 and
the concentrator is connected to AC or DC
power. Recharging time is up to 4 hours for a
single battery and 8 hours for a double
battery. While the Inogen One® G5 is
operating on battery power, the battery will
discharge. The display will indicate the
estimated remaining percentage (%) or
minutes of use.
When the concentrator detects that the
battery life is low, with less than 10 minutes
remaining, a low priority alert will sound.
When the battery is empty, the alert will
change to a high priority.
When battery life is low, do one of the
following:
• Plug the Inogen One® G5 into an AC or
DC power source using the AC power
supply or DC cable.
• Replace the battery with a charged
battery after turning o the Inogen
One® G5 (by pressing the ON/OFF
button). To remove battery press and
hold the battery latch button and slide
battery o the concentrator.
• If the battery is drained, charge
the battery or remove it from the
concentrator.
If the Inogen One® G5 is being powered by the
AC power supply or DC power, batteries will
charge during operation. Leaving your Inogen
One® G5 plugged in past the full charge time
will not harm the concentrator or the battery.
To ensure that your battery is properly
charging, inspect that the correct AC and
10.
