2
TYPICAL APPLICATION
Here is a typical connection diagram used for the TOGGLE device in a videoconferencing setup.
BLOCK DIAGRAM
Here is a simple block diagram of the TOGGLE unit.
USB device1
USB device 2
USB device 3
PC2
PC1
Control:
RS232 / GPI /
USB HID / Push button
USB 3.0/2.0
hub
Power sources:
+12V, PC1 or PC2
MCU
