inogeni TOGGLE User Manual

5
SPECIFICATIONS
Here is the complete specification.
Physical details
Dimensions (W x L x H)
70 x 83 x 23 mm
Power supply
12V
Power consumption
Up to 1.2A
Weight
113 g
Package content
2 x USB 3.0 Type-B to Type-A cables.
1 x terminal block connection.
1 x 12V power supply.
Operating temperature
0° to 45° C (32° to 113° F)
Storage temperature
-40° to 105° C (-40° to 221° F)
Origin
Canada
Warranty
2 years
General specifications
USB host ports
2 x Type-B USB 3.0/2.0 compatible.
USB device ports
3 x Type-A USB 3.0/2.0 compatible.
Serial interface
Baud rate: 9600
For control purpose. See Serial communication protocol section for more
details.
Push-button
Physical switch to select host.
GPIN
Contact-closure control.
Controlled by open-drain IO (short to ground) or driven IO.
Supported voltage range: 0V to +12V max.
Voltage threshold is 0.7V for HW revision 2.0.
Voltage threshold is 2.3V for HW revision 3.0+
2
.
Device current limit
1.8A shared current limit for all 3 x USB device ports.
You can monitor current consumption through RS232 and our Control App.
Software
Upgrade
Field upgradable through our INOGENI Control App.
Control
Automatic, manual or remote control.
Current configuration is saved onboard.
2
Please use the Control App from INOGENI to identify the hardware revision of your product.
