29
Chapter 6 Parameter Description
F0 Group: Basic function group
F0-00 Control mode
Default 2
0 Sensorless vector control (SVC)
1 Reserved
Setting
range
2 V/F control
0: Sensorless vector control
It refers to the open-loop vector and is applicable to general-purpose high performance application
without encoder. One inverter can drive only one motor.
1: Reserved
2: V/F control
It is applicable to the application that does not have high performance requirement and the
application where one inverter drives multiple motors.
Note: motor parameters must be identified if SVC is selected. Refer to Section 4.3 for details.
F0-01 Command source selection
Default 0
0 Keypad control (LED On)
1 Terminal control (LED Off)
Setting range
2 Communication control (LED flashes)
Select the command channels of the inverter.
The On/Off of FWD/REV LED on the panel indicates forward rotation or reverse rotation.
0: Keypad control (LOCAL/REMOT LED is On)
Press the buttons such as RUN, STOP/RES on the keypad panel to perform the running command
control.
1: Terminal control (LOCAL/REMOT LED is Off)
Perform the running command control via the multifunctional input terminals such as FWD, REV,
JOGF, JOGR, etc.
2: Communication control (LOCAL/REMOT LED is flashing)
The running command is provided by upstream device. This option is valid only when a model with
