Inovance MD380 Series

MD380 User Manual Function Code Table
- 137 -
Function Code Parameter Name 0LQ8QLW
Communication
Address
*URXS86WDQGDUG0RQLWRULQJ3DUDPHWHUV
8 AI3 voltage before correction 0.001 V 7017H
8 Linear speed 1 m/Min 7018H
8 Current power-on time 1 Min 7019
8 Current running time 0.1 Min 701AH
8 Pulse reference 1 Hz 701BH
8 Communication reference 0.01% 701CH
8 Encoder feedback speed 0.01 Hz 701DH
8 Main frequency X 0.01 Hz 701EH
8 Auxiliary frequency Y 0.01 Hz 701FH
8 Viewing any register address value 1 7020H
8
Motor temperature 1°C
7022H
8 Target torque 0.1% 7023H
8 Resolver position 1 7024H
8 Power factor angle
0.1°
7025H
8 ABZ position 1 7026H
8 Target voltage upon V/F separation 1 V 7027H
8 2XWSXWYROWDJHXSRQ9)VHSDUDWLRQ 1V 7028H
8 DI state visual display 1 7029H
8 '2VWDWHYLVXDOGLVSOD\ 1 702AH
8
DI function state visual display 1
(functions 01 to 40)
1 702BH
8
DI function state visual display 2
(functions 41 to 80)
1 702CH
8 Fault information 1 702DH
8 Phase Z counting 1 703AH
8 Frequency reference (%) 0.01% 703BH
8 Running frequency (%) 0.01% 703CH
8 AC drive state 1 703DH
8 Current fault code 1 703EH
8
Sent value of point-point
communication
0.01% 703FH
8 Number of slaves 1 7040H
8 Torque upper limit 0.1% 7041H
