Inovance MD380 Series

MD380 User Manual Desc
ription of Function Codes
- 163 -
Value Function Description
10 581GLVDEOHG
The AC drive decelerates to stop, but the running
parameters are all memorized, such as PLC, wobble
function and PID parameters. After this function is
disabled, the AC drive resumes its status before stop.
11 ([WHUQDOIDXOW12LQSXW
,IWKLVWHUPLQDOEHFRPHV21WKH$&GULYHUHSRUWV(UU
and performs the fault protection action. For more
details, see the description of F9-47.
12 Multi-reference terminal 1
The setting of 16 speeds or 16 other references can be
implemented through combinations of 16 states of these
four terminals.
13 Multi-reference terminal 2
14 Multi-reference terminal 3
15 Multi-reference terminal 4
16
Terminal 1 for acceleration/
deceleration time selection
Totally four groups of acceleration/deceleration time can
be selected through combinations of four states of these
two terminals.
17
Terminal 2 for acceleration/
deceleration time selection
18
Frequency source
switchover
The terminal is used to perform switchover between two
frequency sources according to the setting in F0-07.
19
83DQG'2:1VHWWLQJ
clear (terminal, operation
panel)
If the frequency source is digital setting, the terminal
LVXVHGWRFOHDUWKHPRGL¿FDWLRQE\XVLQJWKH83
'2:1IXQFWLRQRUWKHLQFUHPHQWGHFUHPHQWNH\RQWKH
operation panel, restoring the frequency reference to the
value of F0-08.
20
Command source
switchover terminal
If the command source is set to terminal control (F0-02
WKLVWHUPLQDOLVXVHGWRSHUIRUPVZLWFKRYHUEHWZHHQ
terminal control and operation panel control.
If the command source is set to communication control
) WKLVWHUPLQDOLVXVHGWRSHUIRUPVZLWFKRYHU
between communication control and operation panel
control.
21
Acceleration/Deceleration
prohibited
It enables the AC drive to maintain the current frequency
output without being affected by external signals (except
WKH6723FRPPDQG
22 PID disabled
PID is invalid temporarily. The AC drive maintains
the current frequency output without supporting PID
adjustment of frequency source.
23 PLC state reset
:KHQ3/&FRQWUROLVVWDUWHGDJDLQDIWHULWZDVGLVDEOHG
the terminal is used to restore the original status of PLC
control for the AC drive
24 :REEOHGLVDEOHG
The AC drive outputs the central frequency, and the
wobble function is disabled.
25 Counter input This terminal is used to count pulses.
26 Counter reset This terminal is used to clear the counter.
27 Length count input This terminal is used to count the length.
28 Length reset This terminal is used to clear the length.
