Inovance MD380 Series

Description of Function Codes
MD380 User Manual
- 166 -
The four multi-reference terminals have 16 state combinations, corresponding to 16
reference values, as listed in the following table.
Table 6-2 State combinations of the four multi-reference terminals
K4 K3 K2 K1 Reference Setting
Corresponding
Parameter
2)) 2)) 2)) 2)) Reference 0 FC-00
2)) 2)) 2)) 21 Reference 1 FC-01
2)) 2)) 21 2)) Reference 2 FC-02
2)) 2)) 21 21 Reference 3 FC-03
2)) 21 2)) 2)) Reference 4 FC-04
2)) 21 2)) 21 Reference 5 FC-05
2)) 21 21 2)) Reference 6 FC-06
2)) 21 21 21 Reference 7 FC-07
21 2)) 2)) 2)) Reference 8 FC-08
21 2)) 2)) 21 Reference 9 FC-09
21 2)) 21 2)) Reference 10 FC-10
21 2)) 21 21 Reference 11 FC-11
21 21 2)) 2)) Reference 12 FC-12
21 21 2)) 21 Reference 13 FC-13
21 21 21 2)) Reference 14 FC-14
21 21 21 21 Reference 15 FC-15
If the frequency source is multi-reference, the value 100% of FC-00 to FC-15 corresponds to
the value of F0-10 (Maximum frequency).
Besides the multi-speed function, the multi-reference can be also used as the PID reference
source or the voltage source for V/F separation, satisfying the requirement on switchover of
different setting values.
Two terminals for acceleration/deceleration time selection have four state combinations, as
listed in the following table.
Table 6-3 State combinations of two terminals for acceleration/deceleration time selection
Terminal 2 Terminal 1
Acceleration/Deceleration Time
Selection
Corresponding
Parameters
2)) 2)) Acceleration/Deceleration time 1 F0-17, F0-18
2)) 21 Acceleration/Deceleration time 2 F8-03, F8-04
21 2)) Acceleration/Deceleration time 3 F8-05, F8-06
21 21 Acceleration/Deceleration time 4 F8-07, F8-08
Two motor selection terminals have four state combinations, corresponding to four motors,
as listed in the following table.
