Inovance MD380 Series

MD380 User Manual Desc
ription of Function Codes
- 171 -
Function Code Parameter Name Setting Range Default
F4-18 AI curve 2 minimum input 0.00 V to F4-20 0.00 V
F4-19
Corresponding setting of AI
curve 2 minimum input
-100.00% to 100.0% 0.0%
F4-20 AI curve 2 maximum input F4-18 to 10.00 V 10.00 V
F4-21
Corresponding setting of AI
curve 2 maximum input
-100.00% to 100.0% 100.0%
F4-22 $,¿OWHUWLPH 0.00–10.00s 0.10s
Function Code Parameter Name Setting Range Default
F4-23 AI curve 3 minimum input 0.00 V to F4-25 0.00 V
F4-24
Corresponding setting of AI
curve 3 minimum input
-100.00% to 100.0% 0.0%
F4-25 AI curve 3 maximum input F4-23 to 10.00 V 10.00 V
F4-26
Corresponding setting of AI
curve 3 maximum input
-100.00% to 100.0% 100.0%
F4-27 $,¿OWHUWLPH 0.00–10.00s 0.10s
The method of setting AI2 and AI3 functions is similar to that of setting AI1 function.
Function Code Parameter Name Setting Range Default
F4-28 Pulse minimum input 0.00 kHz to F4-30 0.00 kHz
F4-29
Corresponding setting of
pulse minimum input
-100.00% to 100.0% 0.0%
F4-30 Pulse maximum input F4-28 to 50.00 kHz 50.00 kHz
F4-31
Corresponding setting of
pulse maximum input
-100.00% to 100.0% 100.0%
F4-32 3XOVH¿OWHUWLPH 0.00–10.00s 0.10s
These parameters are used to set the relationship between DI5 pulse input and
corresponding settings. The pulses can only be input by DI5. The method of setting this
function is similar to that of setting AI1 function.
Function Code Parameter Name Setting Range Default
F4-33 AI curve selection
8QLWVGLJLW$,FXUYHVHOHFWLRQ
321
Curve 1 (2 points, see F4-13 to F4-16)
Curve 2 (2 points, see F4-18 to F4-21)
Curve 3 (2 points, see F4-23 to F4-26)
Curve 4 (4 points, see A6-00 to A6-07)
Curve 5 (4 points, see A6-08 to A6-15)
Ten's digit (AI2 curve selection)
Same as AI1
Hundred's digit (AI3 curve selection)
Same as AI1
