Inovance MD380 Series

MD380 User Manual Selection and Dimensions
- 285 -
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
&DEOHRI2XWSXW
Side Main Circuit
(mm
2
)
Cable of
Control Circuit
(mm
2
)
Three-phase 480 V
MD380-5T0.7GB 6 9 0.75 0.75 0.5
MD380-5T1.5GB 10 9 0.75 0.75 0.5
MD380-5T2.2GB 10 9 0.75 0.75 0.5
MD380-5T3.7GB 16 12 1.5 1.5 0.5
MD380-5T5.5GB
MD380-5T5.5PB
20 18 2.5 2.5 0.75
MD380-5T7.5GB
MD380-5T7.5PB
32 25 4.0 4.0 0.75
MD380-5T11GB
MD380-5T11PB
40 32 4.0 4.0 0.75
MD380-5T15GB
MD380-5T15PB
50 38 6.0 6.0 0.75
MD380-5T18.5G
MD380-5T18.5PB
50 40 10 10 1.0
MD380-5T22G
MD380-5T22P
63 50 10 10 1.0
MD380-5T30G
MD380-5T30P
100 65 16 16 1.0
MD380-5T37G
MD380-5T37P
100 80 25 25 1.0
MD380-5T45G
MD380-5T45P
125 95 35 35 1.0
MD380-5T55G
MD380-5T55P
160 115 50 50 1.0
MD380-5T75G
MD380-5T75P
225 170 70 70 1.0
MD380-5T90G
MD380-5T90P
250 205 95 95 1.0
MD380-5T110G
MD380-5T110P
315 245 120
120 1.0
MD380-5T132G
MD380-5T132P
350 300 120 120 1.0
MD380-5T160G
MD380-5T160P
400 300 150 150 1.0
MD380-5T200G
MD380-5T200P
500 410 185 185 1.0
