3.Plug in DC Power
4.Attaching the Antennas
GPS Antenna
Connector
DC Power Connector
Main Antenna
Connector
2.Attaching the Bracket
Rotate clockwise and tighten it.
Rotate counterclockwise to remove it.
06
