19
NS-AC10PWH9 / NS-AC12PWH9 / NS-AC10PWH9-C / NS-AC12PWH9-C
www.insigniaproducts.com
Intelligent error indication
If an E1, E2, or E4 error appears on the LED display, turn off your air conditioner and call a professional maintenance
technician or service center.
Understanding your air conditioner’s automatic protection
Anti-freezing protection - When the ambient temperature is very low under Cooling mode, the compressor and motor
will stop working for several minutes if the coil temperature is below 46.4°F (8°C). When the coil temperature increases to
above 46.4°F (8°C), the protection turns off and the previous mode resumes. When anti-freezing protection is active, E4
appears on the display.
Water-full protection - When the water level in the bottom water pan exceeds the warning level, the unit will alert
automatically, “FL” and “Water Full” will flash on the display. Turn off the air conditioner and drain the water as described in
“Emptying the water collection tank” on page 16. After you have drained the water, restart your air conditioner.
Compressor delay protection - Except for the first power-on, the compressor can start instantly. In other cases, the
compressor will start after three minutes delay protection.
Specifications
NS-AC10PWH9/NS-AC10PWH9-C
NS-AC12PWH9/NS-AC12PWH9-C
ERROR CODE DESCRIPTION
E1 Coil temperature sensor error.
E2 Indoor temperature sensor error.
E4
Anti-freezing protection. The air conditioner coil temperature is
too low and the unit has turned off automatically. The unit
resets itself when the temperature reaches 46.4°F (8°C).
FL The internal water tank is full and needs to be emptied.
Dimensions 32.7 x 17.4 x 13.4 in (83 x 44.3 x 34 cm)
Weight 55.1 lb. (25 kg)
Electrical requirements 115V ~60 Hz
Power draw 1.12 Kwh
Power cord length 5.9 ft. (1.8 m)
Dimensions 32.7 x 17.4 x 13.4 in (83 x 44.3 x 34 cm)
Weight 61.7 lb. (28 kg)
Electrical requirements 115V ~60 Hz
Power draw 1.33 Kwh
Power cord length 5.9 ft. (1.8 m)
