www.insigniaproducts.com
10
1.7 or 2.6 Cu. Ft. Compact Refrigerator
11 Align the door bottom so that the pin on the hinge slides into the hole in the door bottom.
12 Align the hinge with the screw holes on the door and the hole in the top edge of the door. Slide the pin through the
hole in the hinge and into the hole on the top edge of the door. Use the screws to attach the hinge to your refrigerator,
but do not tighten the hinge screws. Place the hole cover over the hinge opening on the other side of the door.
13 Make sure that the door seals are snug on all sides when the door is closed, then tighten the upper hinge screws.
Adjust the leveling feet to level the refrigerator.
1.7 cu. ft. refrigerator 2.6 cu. ft. refrigerator
1.7 cu. ft. refrigerator 2.6 cu. ft. refrigerator
