13
2-Door Compact Refrigerator
www.insigniaproducts.com
5 Place the middle hinge pin into the left top of the refrigerator door, then
install the middle hinge on the left of the refrigerator with the screws your
previously removed. Do not fully tighten the screws.
6 Check the fit and alignment (vertical and horizontal) of the door and make
sure that it opens and closes freely, then tighten the screws holding the
middle hinge.
7 Install the pivot pin on the bottom-left of the freezer door using the screw you
previously removed.
8 Align the hole on the bottom-left of the freezer door with the top pin on the
middle hinge, then install the freezer door on the hinge pin.
9 Place the top hinge pin into the top of the freezer door, then install the top
hinge on the top left side of the refrigerator with the screws you previously
removed.
10 Check the fit and alignment (vertical and horizontal) of the door and make
sure that it moves freely open and closed, then tighten the screws holding the
top hinge.
11 Install the screw hole covers you removed previously from the holes on the
top left side of your refrigerator into the holes on the top right of your
refrigerator.
12 Adjust the leveling feet to level the refrigerator.
