11
2-Door Compact Refrigerator
www.insigniaproducts.com
3 Remove the screw hole covers from the top left side of your refrigerator. Keep
the screw hole covers in a handy place. You need them later.
4 Remove the screw holding the pivot pin on the bottom right side of the
freezer door, then remove the pivot pin.
5 Remove the two screws holding the middle hinge to the refrigerator body,
then remove the hinge.
6 Pull the refrigerator door upwards and remove it from the refrigerator.
7 Tilt the refrigerator back.
8 Unscrew the right and left leveling feet, then remove them.
