12
Insignia 3.1 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
7 Unscrew the right and left leveling legs, then remove them.
8 Unscrew the screws holding the bottom hinge on the refrigerator and
remove the hinge.
Reinstalling the doors
1 Install the leveling leg you removed from the left side into the right
bottom of your refrigerator and install the leveling leg you removed
from the right side into the left bottom.
2 Install the bottom hinge on the left bottom of your refrigerator using
the screws your previously removed. Tighten the screws.
3 Align the hole in the bottom left of the refrigerator door with the
bottom hinge pin, then install the door on the hinge pin.
4 Place the middle hinge pin into the left top of the refrigerator door,
then install the middle hinge on the left of the refrigerator with the
screws your previously removed.
