11
4.3 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
3 Remove the screw hole covers from the top left side of your refrigerator.
4 Remove the screw holding the pivot pin on the bottom left side of the freezer door,
then remove the pivot pin.
5 Remove the two screws holding the middle hinge to the refrigerator body, then
remove the hinge.
6 Pull the refrigerator door upwards and remove it from the refrigerator.
7 Tilt the refrigerator back or lay it on its back.
8 Unscrew the right and left leveling feet, then remove them.
Screw
Top hinge
Freezer door
Pivot pin
Screw
Screws (2)
Door hinge cover
