16
www.insigniaproducts.com
10 Use needle nose pliers to remove the thermal insulation foam strip from the
hole you just exposed.
11 Remove the water tube connector, silicone seal, long water supply tube, and
white head screw from the accessory bag, then assemble the parts by aligning
the notch on the silicone seal with the notch on the water tube connector,
inserting one end of the water supply tube into the quick change sealing ring
at the bottom of the connector. Make sure that all parts are securely
assembled.
12 Insert the water supply assembly into the water inlet hole on the back of your
refrigerator, and secure it with the long screw from the accessory bag.
Silicone seal
Water tube connector
Water tube
