13
Ice Maker
www.insigniaproducts.com
Installing the ice maker in a bottom mount freezer
1 Unplug the refrigerator from the wall outlet.
2 Remove the drawers from the freezer compartment.
3 Remove the small screws on both sides of the guide rail of the freezer
compartment door, then remove the freezer compartment door, with the
guide rail support, from the guide rail.
4 Remove the ice maker unit and the connection plate from the accessories bag,
then insert the connection plate into the ice maker unit (as shown below) by
aligning the connection plate with the notch in the ice maker unit.
Connection
plate
Ice maker unit
To Next Page
