4
www.insigniaproducts.com
3 Unplug the refrigerator before performing user maintenance on it.
4 This appliance can be used by children age eight years and older and persons
with reduced physical or mental capabilities or lack of experience and
knowledge if they are given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards involved. Children
should not play with the appliance. Cleaning and maintenance should not be
performed by children without supervision.
5 If a component part is damaged, it must be replaced by the manufacturer, its
service agent, or similar qualified persons in order to avoid a hazard.
6 WARNING: Connect this refrigerator to a potable water supply only.
7 To eliminate the danger of electric shock during installation, you must unplug
the refrigerator.
8 The minimum inlet water pressure should be no lower than 138 kPa (20 PSIG).
The maximum should be no higher than 827 kPa (120 PSIG).
Features
• Produces up to 2.7 pounds of ice a day, depending on the size of your
refrigerator.
• Stores up to 5.5 pounds of ice
• Prevents overflow by automatically detecting when storage bin is full
• Works with these Insignia refrigerators: NS-RBM18SS0, NS-RTM18SS2,
NS-RTM18WH2, NS-RTM18BK2L, NS-RTM18SS2L, NS-RTM18BK2,
NS-RTM18WHD2, NS-RTM18BKD2, and NS-RTM20SS3.
Package contents
Ice maker unit
Ice storage bin
Plastic water supply tubing
Water valve
Water inlet tube
Tube clamp
Leveling bracket
screw
Self-tapping
screws (3)
Ice maker mounting
screws (3)
Plastic clamp (3)
Mounting box
Box cover
Top Mount Freezer only Bottom Mount Freezer only
Water pipe
joint
Sealed silica gel
block
Connecting
plate
To Next Page
