8 Insert the two ice maker mounting screws into the holes in the freezer wall.
Turn each screw clockwise five times.
9 Use needle nose pliers to remove the terminal cover located at the top of the
freezer by first pulling down one side of the cover, then pulling down the
other side. Save the terminal cover for future use in case the ice maker is
removed.
Ice maker mounting
screws
Ter mi na l
Terminal cover
