www.insigniaproducts.com
26
3.7 Cu. Ft. Free-Standing Gas Range for RVs
Disassembling range parts
Disassembling the cook top burners
1 Remove the grate. See Removing the cook top grate on page 24.
2 Use a Phillips screwdriver to remove the two screws on a burner cap, then remove the cap and outer burner head.
3 Remove the two screws on the burner base cap, then remove the cap and burner base.
4 Reverse these steps to reinstall the burner.
CAUTION: To avoid potential damage or injury, these disassemble tasks should only be done by a qualified technician.
