Insignia NS-RNG24SS9 - Accessing Oven Burner Components; Removing Oven Bottom Panel; Removing Pilot Lamp and Burner

www.insigniaproducts.com
28
3.7 Cu. Ft. Free-Standing Gas Range for RVs
3 Use a Phillips screwdriver to remove the two screws on the panel on the bottom of the oven, then remove the panel.
4 Remove the two screws from the pilot lamp and the single screw on the tube burner, then lift the lamp and burner up
and out of the oven.
Pilot lamp
screws
Tube burner screw
