14
www.insigniaproducts.com
10 Attach the upper door self-locking block and the door-open stopper to the
side of the freezer door where the hinge will be. Use the parts from the hinge
kit.
11 Remove the old upper door self-locking block and the door-open stopper (do
not remove the parts attached in step 10). Store in a safe place in case you
need to reverse the door position again.
12 Attach the refrigerator door to the bottom hinge, then attach the center hinge
to the refrigerator. Use the center hinge from the hinge kit (not the piece
removed in step 4).
13 Put the freezer door onto the center hinge, then attach the top hinge (from
the hinge kit) to the top of refrigerator. Cover the hinge with the top hinge
cover (from the hinge kit).
Upper door
self-locking block
Door-open stopper
Freezer door
