15
D3.1 Type of racks and loading
• YELLOW rack: for 18 plates with maximum diameter
of 24
0 mm.
Figure 15
• BLUE rack for glasses: the glasses should be placed
up
side down.
Figure 16
D4
END OF WORK AND DAILY CLEANING
The appliance is designed to carry out an automatic
cleaning cycle to help flush out any residues and to
guarantee greater health and hygiene:
• Open the door and take out the rack containing th
e
clea
n dishes.
• Remove the tank filters and the overflow “W”.
Figure 17
• Close the door.
• Select the drain cycle by pressing “B” button
(Figure 14).
The message "CLE" ("CLEAN") will be displayed
throughout the drain cycle:
• After a few minutes, 3 beeps indicate the end of
the
clea
ning cycle and “END” blinks on the display:
• Switch off the dishwasher by pressing “A” bu
tton
(F
igure 14).
• Switch unit off at the main circuit breaker.
• Close the water shutoff valve.
• Replace the filters and the overflow.
• Remove the top and bottom jets “F” and “I”,
unscrewing the ring nut “H”.
Figure 18
• Carefully clean the washing and rinse jets and cle
an
e
verything with hot water and neutral deter-
gent/detersive, if necessary using a soft brush or
sponge. Do not use sharp implements to clea
n the
n
ozzle holes, which could otherwise be damaged.
• Remove filters “C” and “D” and clean them unde
r a
wate
r spray.
• Remove the filter “Z” and clean away an
y stuck on
foo
d in order to avoid blocking the draining system.
Figure 19
Upon completion of cleaning operations, replace the
parts removed previously.
D4.1 Cleaning the exterior surfaces
Before carrying out any cleaning operations, turn off the
power at the main circuit breaker.
Clean the stainless steel surfaces using warm soapy
water; never use detergents containing abrasive sub-
stances nor steel scrapers, common wire wool, brushes
or scrapers; rinse thoroughly using a wet cloth and care-
fully wipe dry. Clean the control panel using a soft damp
cloth and a neutral detergent if necessary.
Z
1
2
