7
B4 DISPOSAL OF PACKING MATERIAL
All the packaging materials are environmentally safe and
friendly. They maybe kept without fear or danger. They
may be recycled or burned in a special waste incinera-
tion plant. Recyclable plastic components are marked as
follows:
Wood and cardboard components may be disposed of
according to local regulations in force. Appliances that
have reached the end of their service life should be sui-
tably disposed of. The appliance should be dismantled
according to regulations in force. All metal parts are in
stainless steel (AISI 304) and are removable. Plastic
parts are marked with the symbol of the material.
B5 TECHNICAL DATA
Standard cycle time may vary should the inlet water temperature be different from that indicated above.
polyethylene external wrapping film,
instruction bag.
polypropy-
lene
top packaging panels,
straps.
polystyrene
foam
protective surround ele-
ments.
PE
PP
PS
MODEL CADET CDT-1
Supply voltage: 208V, 1ph, 60Hz 33amp
field upgrade to 208V, 3ph 60Hz 20amp
Total Watts 6.85 kW
Booster heating elements 6.0 kW
Tank heating elements 2.2 kW
Water supply pressure 7.25 - 101psi [50 - 700kPa]
Water supply temperature 50°-122°F [10°-50°C]
Water supply hardness for models without incorporated continuous water
softner
140 ppm [14°fH max]
Electric conductivity of water for models without incorporated continuous water
softener
< 1016 S/in /
< 400 S/cm
Concentration of chlorides in water < 20 ppm
Rinse cycle water consumption 0.80 gallons [3 liters]
Booster capacity 3 gallons [12 liters]
Tank capacity 6 gallons [23 liters]
Standard cycle time with water supply at 122°F [50°C] 120 - 240 - 130 seconds
Legal noise level Leq <65dB
Protection rating IPX4
Minimum Supply - Circuit Ampacity 34amp
Net weight 150lb [68kg]
Shipping weight 181lb [82kg]
Shipping width 27 15/16” [710 mm]
Shipping height 41 3/4” [1060 mm]
Shipping depth 30 11/16” [780 mm]
Table 1
