Inspire M5 - Decal Placement

Back Pad Adjustment
Label (235 x 20)
Back Pad Tilt Label
(150 x 70)
DECAL PLACEMENT
PAGE 25
Globe Logo Label
(50mm) Round
“Inspire M5”
below logo
label (50 x 38)
“Do Not Hang From
Press Arm” below
M5 label (50mm)
Round
“WARNING” Label on side
of upright. (40 x 170)
“WARNING,
PINCH POINTS”
on top of base
tube between LE
flats (60 x 40)
Serial number
label (40 x 30)
“Patent” Label
placed just below
the “Warning”
label (50 x 30)
“NOTICE” Label on
side of upright
(40 x 170)
Weight # labels
(1 – 21),
included with
manual. Silver
#’s on black
background.
(18 x 25)
“Inspire” logo on both
sides of the top beam
(127mm x 38mm)
