Insta360 ONE RS Quick Start Guide

①
Push the lock
buckle to the right to
open the lock cover
②
Insert the MicroSD card
(with the label facing the
front side of the Core)
Front side of the
Core (without the
touch screen)
❷
Before use, open the lock cover and insert a MicroSD card.
insta360.com/r/oners_microsd
2）
Be sure to close the lock cover
completely to ensure the waterproofing is
not affected. Align the circular indication
marks as shown to the right. The yellow
indication mark near the lock buckle
should be covered.
Note:
1
）
Please use exFAT formatted microSD cards with the UHS-I bus interface
and Video Speed Class V30 rating (exactly this class, neither higher or lower)
to ensure normal recording. The maximum supported storage space is
1TB. For specific info on supported MicroSD card models, see https://www.
EN
4

Insta360 ONE RS Specifications

General

Bluetooth	Yes
Product color	Black
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Wi-Fi frequency	5 GHz
Camera interface	USB Type-C
Bluetooth version	5.0
Fixed focal length	6.52 mm
Maximum aperture number	2.2
Operating temperature (T-T)	-20 - 40 °C
Fastest camera shutter speed	1/8000 s
International Protection (IP) code	IPX3
HD type	-
Video resolutions	3840 x 1920 pixels
Maximum frame rate	50 fps
Video formats supported	INSV
Maximum video resolution	6144 x 3072 pixels
Image formats supported	INSP, RAW
Maximum image resolution	6528 x 3264 pixels
Storage media	Memory card
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	1000 GB
Audio formats supported	AAC
Virtual Reality (VR) ready	No
Power source	Battery
Battery capacity	1350 mAh
Battery life (max)	1 h
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	129.3 mm
Width	53.2 mm
Height	49.5 mm
Weight	239 g
