8
The following section provides instructions for
attaching the trailer to a bicycle with rear hub nuts
or quick release.
Note: Remove the coupler plate and tab washer
from the end of the tow bar before proceeding.
Trailer Attachment
WARNING!
Use of the trailer without the safety strap attached
to the bicycle may result in serious injury or death.
Always attach the safety strap to the bicycle when
using the trailer.
1.
Using a wrench, remove the hub nut and
washer from the bicycle’s back wheel.
Washer
Hub nut
2.
Place the tab washer on the axle. Fit the tab
into the slot on the bicycle frame dropout.
3.
Place the coupler plate on the axle, in a
vertical position and the large hole down.
Align the pegs on the back of the plate with
the holes in the tab washer.
4.
Place the hub nut and washer back on the axle
and tighten.
Coupler
pegs
Coupler
plate large
hole
Washer
Hub nut
Coupler
plate
Note: If your bike frame doesn’t have a slot in the
drop out, rotate the tab to t in the axle slot.
Axle slot
Tab
Tab
washer
Slot
